ST1 4G Solar-Powered Asset Tracker
Product Detail
ST1 Solar-powered Asset Tracker
In the fast-paced world of logistics and marine transportation, accurate tracking and real-time monitoring are crucial. Our newly launched 4G solar-powered wireless tracker is a game-changer, meticulously crafted to meet the demanding needs of freight and fishing vessels. This state-of-the-art device not only ensures seamless operation but also provides enhanced safety and efficiency for your fleet management.
Features
1. High - Speed 4G Connectivity and Precise Positioning
Combines 4G full - network communication technology with GPS/BDS satellite navigation positioning. This enables real - time, accurate tracking, allowing fleet managers and logistics companies to monitor the location of their vessels at any time. With high - sensitivity GPS/BDS dual - star positioning module and anti - interference ceramic antenna, it ensures stable satellite signal reception, and supports AGPS for fast positioning tracking and synchronous timekeeping.
2. Multiple Alarm Functions for Enhanced Safety
Supports vibration alarm, over - speed alarm, and removal alarm. These functions are essential for fleet management, as they can immediately alert relevant parties in case of abnormal situations. For example, if a vessel is moving at an unauthorized speed or if the tracker is being tampered with, the alarm will be triggered, ensuring the safety of the cargo and the vessel.
3. Electronic Fence Function
Users can define virtual electronic fences through the platform or APP. When the device enters or exits the fence, the platform can identify it and issue an alarm. This is highly beneficial for logistics and freight companies, as it helps in monitoring the movement of vessels within specific areas, such as ports or restricted zones.
4. Solar Charging and Long - Range Battery Life
Solar charging feature ensures an extended battery life, and in power - saving mode, it can operate without the need for additional charging. This is a major advantage for long - distance voyages or areas where access to power sources is limited. For channel distributors, it's a selling point that attracts customers looking for cost - effective and sustainable tracking solutions.
5. Emergency Response and Alarm Notification
Equipped with an SOS emergency button, and can send alarm messages or calls to monitoring numbers when an alarm occurs. The alarm information is also uploaded to the platform simultaneously. This is crucial for fishing vessels and freight ships in case of emergencies, ensuring that help can be dispatched promptly.
6. High - Quality Hardware and Data Transmission
The terminal uses an industrial - grade, highly stable GPRS module from a well - known manufacturer, with a built - in GSM high - sensitivity antenna. It supports TCP/IP data transmission and connection to servers via domain names or IP addresses. This ensures reliable data transfer, which is essential for fleet management service providers and logistics companies to access real - time data.
7. Large - Capacity Data Storage and Blind - Area Data Compensation
Built - in large - capacity storage chip, it supports data storage in offline states. When the vessel is in an area with weak or severely interfered wireless signals, the device temporarily stores the operation data in the FLASH. Once the wireless signal returns to normal, the data can be resent, ensuring no data is lost. This is important for maintaining a complete record of the vessel's journey for analysis and reporting.
8. 3 - Axis Acceleration Sensor and Precise Algorithm
Incorporates a 3 - axis acceleration sensor and a precise acceleration algorithm to continuously monitor the vessel's current posture. Whether it's a sudden tilt or a normal movement, the device can accurately detect and report, providing valuable information for fleet managers to assess the condition of the vessel.
Parameters
| GNSS | ||||
| Positioning System | GPS+BD+LBS | |||
| Frequency | L1 | |||
| Positioning Accuracy | <10m | |||
| Positioning Time | <30ns（1σ） | |||
| Positioning Speed | <0.1m/s（1σ） | |||
| Track Sensitivity | -162dBm | |||
| Acquisition Sensitivity | -148dBm | |||
| TTFF (Open Sky) | Avg. hot start ≤1 s | |||
| Avg. cold start≤ 32s | ||||
| Cellular | ||||
| Communication Network | Asia | Europe | Latam | |
| LTE-FDD/4G | B1/B3/B5/B8 | B1/B3/B5/B7/B8/B20 | B1/B2/B3/B4/B5/B7/B8/B28/B66 | |
| LTE-TDD/4G | B34/B38/B39/B40/B41 | / | / | |
| WCDMA/3G | / | / | / | |
| GSM/2G | / | B3/B8 | B2/B3/B5/B8 | |
| Power | ||||
| Battery | 10000mAh Industrial-grade Li-polymer battery Solar panel self-charging DC 5V1A charging | |||
| Working Modes | Intelligent Modes | Standby Time | Working Mechanism | |
| Regular GPS Mode | Working: upload a position every 30s; Static: upload a heartbeat packet every 5mins ; The device will wake up by vibration | |||
Tracking Mode | The device will only work for 2mins and upload data per preset interval. It won't be woken up by vibration. | |||
| Power-saving Mode | Up to 2 years | Working: upload a position every 30s; Static: no data uploading; The device will be waked up by vibration | ||
| Interfaces | ||||
| LED Indication | Status indicator (Red), GSM Indicator (Yellow), GPS Indicator (Blue) | |||
| SIM | Nano-SIM | |||
| Tamper proof | Built-in light sensor, G-sensor, microphone | |||
| Temperature Detection | –20℃ to +75℃ (±0.5℃) | |||
| Size | 138mm * 77mm * 30mm, 300g | |||
| Resistant Level | IP67 | |||
| Multiple Alerts | Low battery alert, tamper alert, vibration alert, removal alert, power-off alert | |||
